镀锌风管的优势你知道多少呢？

发布人：http://www.sftfgd.com   发布时间：2018-11-13 11:28:29

镀锌风管的优势

Advantages of galvanized air ducts

1.机械加工成型的制作能够使镀锌板不易受到损坏，使镀锌层不轻易被损伤，这样很好的增加了风管的使用时间。

1. The manufacture of mechanical forming can make galvanized sheet not easy to be damaged and galvanized layer not easy to be damaged, which greatly increases the service time of air duct.

2.规格一样，尺寸标准，保证了风管内部平整，光滑，便于清洁 ，可以使物料输送流畅。

2. The same specifications, size standards, to ensure that the inside of the duct is smooth, smooth, easy to clean, can make material delivery smooth.

3.自成型法兰的管道它使用的材料统一，没有使用角钢法兰，这样可以大大减轻了风管本身的重量，这样建筑物的承荷能力将会大大减小，这样就从根本上减少了建筑物的造价。

3. The pipes with self-forming flange use uniform materials and do not use angle steel flange, which can greatly reduce the weight of the air duct itself, so that the bearing capacity of the building will be greatly reduced, thus fundamentally reducing the cost of the building.

4.加强了风管自身的美观，主要有，构造上的精巧，外观线条上的柔和，使用性能上的。

4. Strengthen the beauty of the air duct itself, mainly in its delicate structure, soft appearance and excellent performance.

5.因为是标准化的生产流程，所以风管的气密性很好，严谨的流水线制作，使每个风管的部件及接头和零配件都有良好的密封性。

5. Because it is a standardized production process, the air tightness of the air duct is very good, rigorous production line, so that each air duct parts and joints and spare parts have good sealing.

6.标准化加工产生的加强筋、压筋，增强了管道自身的强度，减少了材料的厚度，大大降低了成本。螺旋风管的咬口潜缝厚度是管体的4倍，使管道的刚性非常大，拥有较优的承压能力。

6. The reinforcing bars and compressing bars produced by standardized processing enhance the strength of the pipeline itself, reduce the thickness of the material and greatly reduce the cost. The thickness of the submerged slot of the spiral duct is four times that of the tube body, which makes the pipeline very rigid and has the best pressure bearing capacity.

7.采用的焊接方式具有特色，低温焊接的方式，从而可以保证产品的镀层不轻易被损坏，这样做出的部件及牢固又美观且密封性较好，焊后不用做处理。

7. The welding method adopted has its own characteristics. The low temperature welding method can ensure that the coating of the product is not easily damaged. The parts made in this way are firm, beautiful and sealable, and need not be treated after welding.

安装镀锌风管的时候应该注意的事情

Something to note when installing galvanized duct

1.在安装前需要检查产品是否合格，如果合格就进行部件的组装，较后再进行风管的清洁与高空的安装。

1. Before installation, we need to check whether the product is qualified. If it is qualified, we need to assemble the components. Finally, we need to clean the air duct and install it at high altitude.

2.产品在安装时，应控制每个风管之间的间距小于4M，尤其是单个直管之间必须要有不低于2个及以上的固定位定住。

2. When installing the product, the distance between each air duct should be controlled to be less than 4M. Especially, there must be no less than two or more fixed positions between single straight duct.

3.在安装产品过程中，需要使用的调隔离的振支和吊杆拉伸，应当根据设计的要求和实际的情况进行适当的修改。

3. In the process of installing products, the vibration support and suspender tension which need to be adjusted and isolated should be modified appropriately according to the design requirements and actual conditions.

4.镀锌风管吊架的螺孔可使用机械加工进行安装。同时吊杆应保持平直，螺纹完整和光洁。安装之后应检查各副支、吊架之间的受力是否均匀。

4. the screw hole of the galvanized air duct hanger can be installed by mechanical processing. Meanwhile, the hanger should be straight and threaded. After installation, check whether the forces between the sub supports and hangers are even.

5.在安装镀锌风管的弯管时，一定要添加导流片，以确保风管有正常的输送风力。如果是矩形弯管的话，可以采用三通或者四通进行连接，安装的方式大多数采用分叉式或分隔式进行安装。

5. When installing the elbow of galvanized duct, the guide vane must be added to ensure that the duct has normal conveying wind power. If rectangular elbow is used, three-way or four-way connection can be used. Most of the installation methods are bifurcated or separated.

6.在安装过程中要特别注意风管和法兰之间翻边的情况，应尽量保证翻边的平整，保持连接宽度的一致。

6. In the process of installation, special attention should be paid to the flanging between the air duct and the flange, and the flanging should be as smooth as possible to maintain the consistency of the connection width.

较后有一个重要的环节，就是要注意风管吊杆的施工，要做好高度统一的调节工作，只有高度一致的时候，每个吊杆才能够充分发挥各自的作用。

Finally, there is an important link, that is to pay attention to the construction of air duct hangers, to do a highly unified adjustment work, only when the height of consistency, each hanger can give full play to their respective roles.
