镀锌螺旋风管与玻璃钢风管的性能比较

发布人：http://www.sftfgd.com   发布时间：2019-05-09 17:08:55

　　一、保温性能对比：

　　1. Comparison of thermal insulation performance:

　　无机玻璃钢风管：导热系数大，无保温性能，必须另外加包保温层及保温防护层，保 温层特性同镀锌风管。

　　Inorganic fiberglass reinforced plastic duct: It has large thermal conductivity and no thermal insulation performance. It must be coated with thermal insulation layer and thermal insulation protection layer. The thermal insulation layer has the same characteristics as galvanized duct.

　　镀锌螺旋风管：导热系数大，无保温性能，需另外加包保温层。

　　Galvanized spiral air duct: large thermal conductivity, no thermal insulation performance, need to add additional thermal insulation layer.

　　二、强度对比：

　　Strength contrast:

　　无机玻璃钢风管：强度较高，但比较脆弱，应其较重，不易搬运，易受碰撞导致酥裂和破损， 因自重较大，水平面边长较大时风管壁厚迅速增加，单位面积管壁重量大大增加，容易产生性竖向变 形和沉降（规范规定矩形无机玻璃钢风管也应同按金属风管的加固方法进行加固，其加固筋与风管应为相同的材料并成为一整体）。

　　Inorganic fiberglass reinforced plastics ducts: high strength, but relatively fragile, should be heavier, not easy to handle, vulnerable to collision leading to cracking and damage, because of heavy weight, large horizontal side length when the duct wall thickness increases rapidly, unit area wall weight increases greatly, prone to permanent vertical deformation and settlement (specification stipulates that rectangular inorganic fiberglass reinforced plastics ducts should also be added with metal ducts) The reinforcing bars and air ducts should be the same material and become a whole.

　　镀锌螺旋风管：强度较高，抗静压能力强，易搬运，受碰撞不会导致破损。

　　Galvanized spiral air duct: high strength, strong static pressure resistance, easy to transport, collision will not lead to damage.

　　三、防潮性能对比：

　　3. Comparisons of moisture-proof performance:

　　无机玻璃钢风管：无法与有机玻璃钢风管的防潮性能相比，受原料配比的制约，其防潮能 力的稳定性较差；受市场竞争的影响，为降低成本，使目前市场上出现的无机玻璃钢风管绝大多数不能符 合相关标准。

　　Inorganic FRP duct: Compared with the moisture-proof performance of organic FRP duct, the stability of moisture-proof ability of inorganic FRP duct is poor due to the restriction of raw material ratio. Influenced by market competition, in order to reduce costs, most of the inorganic FRP ducts on the market can not meet the relevant standards.

　　镀锌螺旋风管：不适合在空气潮湿性大的环境使用、在此种环境使用易腐蚀生锈。

　　Galvanized spiral air duct: It is not suitable for use in humid environment. It is easy to corrode and rust in this environment.

　　四、漏风量对比：

　　Comparisons of air leakage:

　　《规范》规定：风管漏风量应根据管道长短及其气密程度，按系统风量的百分率计算。风管漏风率宜采用10%（对于一般送排风系统）玻璃钢风管总长度50m以下时，其漏风率通常要达到 8-10%， 风管总长度增加时，漏风量要适当增加，当管内静压为500Pa时，风管单位面积漏风量为6m3 /h.m2 。

　　The Code stipulates that the air leakage rate of air duct shall be calculated according to the length of the duct and its air tightness, and the percentage of the air flow rate of the system. When the total length of FRP duct is less than 50 m, the air leakage rate usually reaches 8-10%. When the total length of duct increases, the air leakage rate should be increased appropriately. When the static pressure inside the duct is 500 Pa, the air leakage rate per unit area of duct is 6 m3/h.m2.

　　镀锌螺旋： 风管总长度50m以下时，其漏风量通常要达到 8%，风管总长度增加时，漏风量要适当增加。

　　Galvanized spiral: When the total length of air duct is less than 50m, the air leakage usually reaches 8%. When the total length of air duct increases, the air leakage should increase appropriately.

　　五、 防火性能对比：

　　Fifth, fire protection performance comparison:

　　无机玻璃钢风管：无机玻璃钢风管属不燃材料，但其保温材料是否燃烧要依材质而定，通 常选用离心玻璃棉等不燃保温材料，而聚苯乙烯板等则不能满足要求。

　　Inorganic FRP duct: Inorganic FRP duct belongs to non-combustible material, but its thermal insulation material depends on the material. Usually, centrifugal glass wool and other non-combustible thermal insulation materials are selected, while polystyrene board can not meet the requirements.

　　镀锌风管：镀锌螺旋风管属不燃材料，其保温材料是否燃烧要依材质而定，通常要选用离心玻璃棉等不燃保温材料。

　　Galvanized air duct: Galvanized spiral air duct belongs to non-combustible material. Whether its insulation material burns or not depends on the material. Usually, non-combustible heat preservation material such as centrifugal glass wool should be selected.

　　六、 消声性能对比：

　　6. Comparison of noise attenuation performance:

　　玻璃钢风管：无消声性能，必须加装消声器，且需要更大的空间FRP duct: silence performance, muffler must be installed, and need more space镀锌风管： 无消声性能，必须加装消声器，同玻璃钢风管一样，多占 用空间。

　　Galvanized air duct: silencing performance, muffler must be installed, as with FRP air duct, occupy more space.
