通风管道设备安装的规范细则

发布人：http://www.sftfgd.com   发布时间：2020-05-20 14:32:52

通风是一种换气设备，它是用机械或自然的方法向室内空间送入足够的新鲜空气，同时把室内不符合卫生要求的污浊空气排出，使室内空气满足卫生要求和生产过程需要，通风管道设备有着十分广泛的使用范围。下面小编就来为大家介绍一下通风管道设备安装的规范细则以及常见问题。

Ventilation is a kind of ventilating equipment, it uses mechanical or natural methods to send enough fresh air to the indoor space, and at the same time, it discharges the dirty air that does not meet the sanitary requirements, so that the indoor air can meet the sanitary requirements and the needs of the production process. The ventilation pipe equipment has a very wide range of use. The following small edition will introduce the specification details and common problems of the installation of ventilation pipeline equipment for you.

当今，建筑中完成通风工作的各项设施，统称通风管道设备。通风管道设备分排风扇，换气扇，风机等，又分工业用及家用二种。而风机又分高、中、低、负压等。

Nowadays, the ventilation facilities in the building are collectively referred to as ventilation pipe equipment. The ventilation duct equipment is divided into exhaust fan, ventilation fan, fan, etc., and is divided into industrial and household two kinds. And the fan is divided into high, medium, low, negative pressure and so on.

通风管道设备安装的规范细则

Specification for installation of ventilation pipeline equipment

1、通风机安装应符合下列规定

1. The fan installation shall meet the following requirements

（1）风机试运转时，叶轮旋转方向正确，经不少于2H运转后，滑动轴承温升不超过35度，温度不超过70度；滚动轴承温升不超过40度，温度不超过80度。

(1) During the test run of the fan, the rotating direction of the impeller is correct. After not less than 2h of operation, the temperature rise of the sliding bearing shall not exceed 35 degrees and the maximum temperature shall not exceed 70 degrees; the temperature rise of the rolling bearing shall not exceed 40 degrees and the maximum temperature shall not exceed 80 degrees.

（2）离心风机与减震台座接触紧密，螺栓拧紧，并有防松装置。

(2) The centrifugal fan is in close contact with the shock absorption pedestal, the bolts are tightened, and there is a locking device.

（3）管道风机采用减震吊架安装时，风机与减震吊架连接紧密，牢固可靠；采用支拖架安装时，风机与减震器及支架、托架连接紧密，稳固可靠。

(3) When the pipeline fan is installed with damping hanger, the connection between the fan and damping hanger is tight, firm and reliable; when it is installed with support and towing frame, the connection between the fan and shock absorber, bracket and bracket is tight, firm and reliable.

2、过滤器、纸除尘器、过滤器吸收器安装应符合下列规定

2. The installation of filter, paper dust remover and filter absorber shall meet the following requirements

（1）各种设备的型号、规格、额定风量必须符合设计要求。

(1) The model, specification and rated air volume of various equipment must meet the design requirements.

（2）各种设备的安装方向必须正确。

(2) The installation direction of various equipment must be correct.

（3）设备与管路连接时，宜采用整体性的橡胶软管接头，并不得漏气；固定支架应平正稳定。

(3) When the equipment is connected with the pipeline, the integral rubber hose joint should be used without air leakage; the fixed bracket should be flat and stable.

（4）过滤器的安装应固定牢固，过滤器与框架、框架与维护结构之间无明显缝隙。

(4) The installation of filter shall be fixed firmly, and there shall be no obvious gap between filter and frame, frame and maintenance structure.

（5）纸除尘器和过滤器的安装，应固定牢固，位置准确，连接严密。

(5) The installation of paper dust remover and filter shall be fixed firmly, with accurate position and tight connection.

3、消声器安装应符合下列规定

3. The installation of muffler shall meet the following requirements

（1）消声器框架必须牢固，共振腔的隔板尺寸贴紧，正确，隔板与壁板结合处外壳严密不漏。

(1) The muffler frame must be firm, the diaphragm size of the resonance chamber shall be close and correct, and the shell at the joint of diaphragm and wall plate shall be tight without leakage.

（2）消声器安装方向必须正确，并单独设置支（吊）架。

(2) The installation direction of muffler must be correct, and the support (hanger) shall be set separately.

（3）消声片单独安装后固端必须牢固，片距均匀。

(3) The fixed end of the silencing piece shall be firm and the distance between pieces shall be even after it is installed separately.

（4）消声片状材料粘结牢固、平整，散状材料充填均匀、无明显下沉。

(4) The anechoic sheet material is firmly and smoothly bonded, and the scattered material is evenly filled without obvious sinking.

（5）消声复面材料顺气流方向拼接，无损坏；穿孔板无毛刺，孔距排列均匀。

(5) The material of noise elimination compound surface is spliced along the air flow direction without damage; the perforated plate is free of burr and the hole spacing is evenly arranged.

4、密闭阀门安装，应符合下列规定

4. The installation of airtight valve shall meet the following requirements

（1）安装前应进行检查，其密闭性能应符合产品技术要求。

(1) Inspection shall be conducted before installation, and its sealing performance shall meet the technical requirements of the product.

（2）安装时，阀门上箭头标志方向与冲击波的方向一致。

(2) During installation, the direction of arrow mark on the valve is consistent with the direction of shock wave.

（3）开关指示灯的位置与阀门板的实际开关位置应相同，启闭手柄的操作位置应准确。

(3) The position of the switch indicator light shall be the same as the actual switch position of the valve plate, and the operation position of the opening and closing handle shall be accurate.

（4）阀门应用吊钩或支架固定。

(4) The valve shall be fixed by hook or bracket.

5、测压装置安装，应符合下列规定

5. The installation of pressure measuring device shall meet the following requirements

（1）测压管连接应采用焊接，并应满焊、不漏气。

(1) The piezometric pipe shall be connected by welding and shall be fully welded without air leakage.

（2）管路阀门与配件连接应严密。

(2) The connection between pipeline valve and accessories shall be tight.

（3）测压板应做防腐处理和膨胀螺丝固定。

(3) The pressure plate shall be treated with anti-corrosion and fixed with expansion screws.

（4）测压仪器应保持水平安置。

(4) The pressure measuring instrument shall be placed horizontally.

以上是对通风管道安装规范细则的详细介绍，由山东通风管道友情奉献，想了解更多请点击官网http://www.sftfgd.com。

The above is a detailed introduction to the detailed rules and regulations for the installation of ventilation pipes. Shandong Ventilation Pipe Co., Ltd. is dedicated to you. For more information, please click the official website http://www.sftfgd.com 。
