通风管道安装怎样开展合理布局?

发布人:http://www.sftfgd.com   发布时间:2021-02-06 17:31:43

通风管道铺装明晰装、暗埋,一般选用明装。由于明装便于于维修,在没法选用明装时考虑到暗埋方法,管道尽量的集中化陈列,尽可能沿墙或柱头平行面铺装,若管经大或隔热保温应合理布局在贴墙侧。一般二根管道平行面合理布局时,间隔不小于100~200mm。

The ventilation pipe is clearly installed and buried, and the open installation is generally selected. As the open installation is convenient for maintenance, when it is impossible to select the open installation, the buried method should be considered. The pipelines should be displayed in a centralized way as far as possible, and paved along the parallel surface of the wall or column head as far as possible. If the pipe diameter is large or the heat insulation should be reasonably arranged on the wall side. Generally, when the parallel planes of two pipes are reasonably arranged, the interval shall not be less than 100-200 mm.

通风管道加工系统软件的连接标准:

Connection standard of ventilation pipe processing system software:

在以电焊焊接为关键接口方式方式的管道中,应设定充足总数的法兰联接,在以外螺纹为导向的联接管道中应设定充足的活接头,通风管道便于宜在安装、拆装、维修。

In the pipeline with electric welding as the key interface mode, sufficient number of flange connection shall be set. In the connection pipeline with external thread as the guide, sufficient movable joints shall be set. The ventilation pipeline is convenient for installation, disassembly and maintenance.

通风管道安装加工系统软件的支撑点标准管道不适合与各种阀门立即支撑点在机器设备上,应独立设定支撑架或支架,管道的焊接部位应在工程施工便捷或承受力较小的地区,焊接不可坐落于支撑架处且间距不小于200mm。

The standard pipe is not suitable for the immediate support point of various valves. The support frame or bracket should be set independently on the machinery and equipment. The welding position of the pipe should be in the area with convenient engineering construction or low bearing capacity. The welding should not be located at the support frame and the spacing should not be less than 200 mm.


不一样烟尘汽体特性不一样,则清洁的按段解决应不一样。通风管道加工系统软件合理布局时要确保总体系统软件的漏损小,保证 除尘口的有充足的排风量。通风管道加工系统软件合理布局要减少摩擦阻力。

If the steam characteristics of different soot are different, the cleaning methods should be different. When the software layout of the ventilation pipe processing system is reasonable, it is necessary to ensure that the leakage of the overall system software is small, and that there is sufficient exhaust air volume at the dust outlet. The reasonable layout of the software of the ventilation pipe processing system should reduce the friction resistance.

环形风管抗压强度大耗品少,但加工加工工艺繁杂些,占有室内空间大;不锈钢风管易布局,非常容易加工,因此应用比较广泛。济南通风管道加工也有系机械自动化生产制造由尼龙带螺旋式线圈电感而成,有环形、矩形框,为节约室内空间,很多的不锈钢风管制成扁圆。

The annular air duct has high compressive strength and few consumables, but the processing technology is more complicated and occupies a large indoor space; the stainless steel air duct is easy to layout and process, so it is widely used. Jinan ventilation pipe processing also has mechanical automation production, which is made of nylon belt spiral coil inductor, with ring and rectangular frame. In order to save indoor space, many stainless steel air pipes are made into flat circle.

有关通风管道的排风方法

Exhaust method of ventilation pipe

通风管道是特意为一处或几个屋子或机器设备排风和排风系统的管道。排烟系统管道是特意共排烟尘的管道,就主要用途而言有各自,就管道本身讲全是管道。设备完的风管要确保表面润化整洁,户外风管需有防水防雨、防雪对策。风管伸进结构风管时,其尾端应设备上钢丝网片,防止系统软件运行时,脏物进到金属材料风管内。金属材料风管与结构风管间隙应堵漏密不可分。风管穿越重生变形缝时要按设计方案要求增设防水套管,防水套管与风管的空隙用填充料(软塑)堵漏密不可分,从这种特点大家应当可以迅速的鉴别开二者的差别。餐厅厨房房间内的管道布局要遵照“短”标准,少用弯管,尤其是大视角弯管。这类走管方法和空调的“横纵齐整”各有不同,目地是确保排厨房油烟实际效果,还能够节约。排烟罩上边的集支气管的主出入口排烟罩的中间部位。

Ventilation pipe is a pipe specially designed for exhaust and exhaust system of one or several rooms or machinery and equipment. The smoke exhaust system pipe is specially designed to exhaust smoke and dust. In terms of main uses, it has its own characteristics. In terms of the pipe itself, it is all pipes. The surface of the air duct after the equipment is finished shall be moist and clean, and the outdoor air duct shall be provided with waterproof, rain proof and snow proof measures. When the air duct extends into the structural air duct, the end of the air duct should be equipped with steel mesh to prevent dirt from entering the metal air duct when the system software is running. The gap between metal material air duct and structural air duct should be closed. When the air duct passes through the rebirth deformation joint, the waterproof sleeve should be added according to the design requirements. The gap between the waterproof sleeve and the air duct should be plugged with filler (soft plastic). From this characteristic, we should be able to quickly identify the difference between the two. The pipe layout in the dining room and kitchen room should follow the "short" standard, and use less elbow, especially the elbow with large angle of view. This kind of pipe running method is different from the "horizontal and vertical neat" of the central air conditioner. The purpose is to ensure the actual effect of exhausting kitchen lampblack and save energy. The middle part of the main entrance and exit smoke hood of the collecting tube on the upper side of the smoke hood.
