通风管道的连接有哪些方法？

发布人：http://www.sftfgd.com   发布时间：2021-05-17 11:24:49

我们在安装通风管道时，不是固定不变的方法，而是有多种方法，可以根据自己的情况选择一种简单方便的，这个也决定我们的呈现效果，先来看一下它都有哪些方法供大家选择？

When we install ventilation ducts, there are many methods, not fixed methods. We can choose a simple and convenient method according to our own situation, which also determines our presentation effect. Let's first see what methods are available for you to choose?

1、插接式连接：主要用于矩形或圆形风管连接，制作连接管，然后插入两侧风管，再用拉铆钉将其紧密固定。

1. Plug in connection: it is mainly used for the connection of rectangular or circular air duct. First, make the connecting pipe, then insert the air duct on both sides, and then fix it tightly with rivet.

2、插条式连接：主要用于矩形风管连接，它是将不同形式的插条插入风管两端，然后压实即可。

2. Slotted connection: it is mainly used for rectangular duct connection. It is to insert different forms of slotted bars into both ends of the duct, and then compact them.

3、软管式连接：主要用于风管与部件的相连，安装的时候，软管两端套在连接的管外，然后用特别软卡把软管箍紧。

3. Hose type connection: it is mainly used to connect the air duct and components. During installation, both ends of the hose are sheathed outside the connecting pipe, and then the hose is clamped tightly with a special soft clamp.

4、抱箍式连接：主要用于钢板的圆通风管道和螺旋风管连接，先把每一管段的两端轧出鼓筋，并使其一端缩为小口，安装时按气流方向把小口插人大口，外面用钢制抱箍将两个端的鼓箍抱紧连接，用螺栓穿在环中间固定拧紧。

4. Hoop type connection: it is mainly used for the connection of circular ventilation pipe and spiral air pipe of steel plate. Firstly, the two ends of each pipe section are rolled out with ribs, and one end is shrunk to a small opening. During installation, the small opening is inserted into the big opening according to the air flow direction, and the drum hoops at the two ends are tightly connected with steel hoops, and fixed and tightened with bolts in the middle of the ring.

以上就是我们在连接通风管道时常用的几种方法，希望对大家有用，更多信息欢迎关注本站更新。

The above are several common methods when we connect the ventilation duct, hope to be useful to you, more information, welcome to pay attention to the update of this site.
