通风管道应用工业除尘该如何进行合理布局？

发布人：http://www.sftfgd.com   发布时间：2021-06-25 13:57:23

　　工业除尘系统软件管道,作为一个辅助工业生产环境的美化,合理布局的简单和紧凑,平整美观,安装方便、实际操作、维护和其他因素做出合理化的管道系统软件,然后工业除尘系统如何安排软件管道合理吗?

　　Industrial dust removal system software pipeline, as an auxiliary industrial production environment beautification, reasonable layout of simple and compact, flat and beautiful, easy to install, practical operation, maintenance and other factors to make reasonable pipeline system software, and then industrial dust removal system how to arrange software pipeline reasonable?

　　1.管道合理布置通用标准

　　1. General standard for reasonable pipeline layout

　　在除尘设备的扬尘风管中，其烟尘或有害物质或其他物质的特性会有所不同。须考虑不同的差异。须遵循的标准是:

　　In the dust duct of dust removal equipment, the characteristics of dust or harmful substances or other substances will be different. Different differences have to be considered. The standards to be followed are:

　　如何合理安排工业除尘通风管道?

　　How to arrange industrial dust removal ventilation pipe reasonably?

　　1.不同的烟尘蒸汽特性是不同的，所以清洗溶液应根据不同的段落而不同。

　　1. The steam characteristics of different soot are different, so the cleaning solution should be different according to different paragraphs.

　　当污染物较多时，可以集中在一个净化设备中，也可以分为多个系统软件。但是，空气污染物的混合会产生着火、爆炸的危险，产生不同温度和环境湿度的蒸汽，混合后会出现管道。其内部凝结物、烟气和蒸汽的特性不同，危及采集和清洗的效率。

　　When there are many pollutants, they can be concentrated in one purification equipment or divided into multiple system software. However, the mixing of air pollutants will produce the danger of fire and explosion, and produce steam with different temperatures and environmental humidity. After mixing, pipes will appear. The characteristics of condensate, flue gas and steam are different, which endangers the efficiency of collection and cleaning.

　　2.管道系统软件的合理布置应降低管道系统的摩擦阻力

　　2. The reasonable layout of pipeline system software should reduce the friction resistance of pipeline system

　　一般环形风道抗压强度高，原材料损耗小，但室内空间大。矩形方管占据室内空间小，便于合理布置，但也要遵循室内空间条件。

　　Generally, the annular air duct has high compressive strength, small loss of raw materials, but large indoor space. Rectangular square tube occupies a small indoor space, which is convenient for reasonable layout, but it should also follow the indoor space conditions.

　　3.管道系统软件的路面标准

　　3. Pavement standard of pipeline system software

　　管道铺设一般有隐蔽安装和隐蔽埋设两种形式。一般采用隐蔽安装，便于维护。不能隐蔽安装的，应当考虑隐蔽埋设的方法。平行面铺装，管道较大或隔热时，应合理布置在墙侧。一般情况下，两条管道的平行面布置合理时，间隔不应小于100~200mm。

　　Pipeline laying generally has two forms: concealed installation and concealed burying. Generally, concealed installation is adopted for easy maintenance. If the installation cannot be concealed, the method of concealed burying shall be considered. When parallel surface pavement, large pipeline or heat insulation, it should be reasonably arranged at the wall side. Generally, when the parallel plane of two pipelines is reasonably arranged, the interval should not be less than 100 ~ 200 mm.

　　4.管道支撑点标准

　　4. Pipe support point standard

　　该管道不适合直接支撑设备上的各种阀门。支撑架或托架应独立安装。管道焊接位置应在施工方便或支撑小的区域。焊接不应位于支撑架上，间隔不小于200mm。

　　The pipeline is not suitable for directly supporting various valves on the equipment. The support frame or bracket shall be installed independently. The welding position of pipeline shall be in the area with convenient construction or small support. The welding shall not be located on the support frame, and the interval shall not be less than 200 mm.

　　5.管道连接标准

　　5. Pipe connection standard

　　在以电焊为关键接口方式的管道中，应设置足够的松法兰总数，以外螺纹为主的管道连接应设置足够的松接头，便于安装、拆卸、装配和装配。服务。

　　In the pipeline with electric welding as the key interface mode, enough loose flanges shall be set. In the pipeline connection with external thread as the main thread, enough loose joints shall be set to facilitate installation, disassembly, assembly and assembly. Services.

　　6.管道布置合理时，应保证系统整体软件泄漏量小，并保证除尘口排气风量充足。

　　6. When the pipeline layout is reasonable, the overall software leakage of the system should be small, and the exhaust air volume of the dust removal outlet should be sufficient.

　　2.管网系统软件网络布局合理

　　2. The software network layout of pipe network system is reasonable

　　为了便于管网管理方法和运行调整，管网系统软件不宜太大。当同一系统软件中有多个支管时，应对支管电平进行分类控制，且同一系统软件的呼吸点不同。对于过多的防护服，须注意各隔水管工作压力的平衡。常见的管网合理布置方式有穿管、部分穿管和环穿管三种。一般情况下，水平管的水流速率<3m/s，竖直管的水流速率<6m/s。

　　In order to facilitate the pipe network management method and operation adjustment, the pipe network system software should not be too large. When there are multiple branches in the same system software, the branch level should be classified and controlled, and the breathing points of the same system software are different. For excessive protective clothing, attention should be paid to the balance of working pressure of each riser. There are three common ways of reasonable pipe network layout: through pipe, part through pipe and ring through pipe. Generally, the flow rate of horizontal pipe is less than 3m / s, and that of vertical pipe is less than 6m / s.
