风管加工制作期间的5个要点

发布人：http://www.sftfgd.com   发布时间：2023-07-19 10:37:18

风管的制作重要的就是规范性，每一个细节的处理都会影响后的使用，所以我们要注意处理的方法，对于每一个方面的处理下面都进行了简单的总结，下面济南风管加工厂为您分析：

The important thing for the production of air ducts is standardization, and the handling of every detail will affect their subsequent use. Therefore, we need to pay attention to the handling methods. Below is a brief summary of each aspect of the handling. Jinan Air duct Processing Factory will analyze for you:

1、风管段制作。风管段加工制作时，必须注意边角位置的漏洞。应该以机械密封为主，辅助以密封胶处理。每段管道加工成型后，需要作质量检查。从现场施工考察，角铁法兰强度及密封性能，远高于共板法兰。在变风量系统中，建议使用角铁法兰为主。

1. Production of air duct sections. When processing and manufacturing air duct sections, attention must be paid to the loopholes at the edges and corners. Mechanical sealing should be the main method, supplemented by sealant treatment. After each section of pipeline is processed and formed, quality inspection is required. From on-site construction inspection, the strength and sealing performance of angle iron flanges are much higher than those of common plate flanges. In variable air volume systems, it is recommended to mainly use angle iron flanges.

2、风管弯头制作。风管弯头位置应按规范要求设置倒流片，特别是尺寸较大弯头，会影响气流及造成局部噪音。在导流片设定时，应注意合理位置及片数。变风量系统中，风量是根据末端需求而变化。由于风管内流速、流量会发生变化，因此弯头合理的设置会有利于减少局部阻力。

2. Production of air duct elbows. The position of the air duct elbow should be equipped with a backflow plate according to the specification requirements, especially for larger elbows, which can affect the airflow and cause local noise. When setting the guide vanes, attention should be paid to the reasonable position and number of vanes. In a variable air volume system, the air volume varies according to the end demand. Due to changes in flow velocity and flow rate inside the air duct, a reasonable setting of the elbow will be beneficial for reducing local resistance.

3、风管法兰制作。由于风管采用钢板法兰连接，尺寸较大的三通、弯头等制作需要拼接板材。但是，钢板法兰位置严格不允许拼接。其强度不能达到要求，须采用角钢法兰或按设计及规范要求处理。在变风量系统中，由于管道内保持较稳定的静压状态，对风管强度及密封性能要求较高。

3. Manufacturing of air duct flanges. Due to the use of steel plate flanges for air ducts, the production of larger tees, elbows, etc. requires splicing of plates. However, the position of the steel plate flange strictly does not allow splicing. Its strength cannot meet the requirements, and angle steel flanges must be used or treated according to the design and specification requirements. In a variable air volume system, due to maintaining a relatively stable static pressure state in the pipeline, there are high requirements for the strength and sealing performance of the air duct.

4、风管三通制作：在VAV变风量系统中，由于三通两侧的风量在不同工况下会发生变化，而隔板或倒流片会严重限制了风量的分配，因此三通位置不能加装导流板或中间加固隔断。但部件强度必须符合设计及规范要求，请采用角钢法兰或按设计及规范要求加固处理。

4. Air duct three-way production: In VAV variable air volume systems, due to changes in air volume on both sides of the three-way under different operating conditions, and partitions or backflow sheets severely limiting the distribution of air volume, the three-way position cannot be equipped with guide plates or reinforced partitions in the middle. But the strength of the components must meet the design and specification requirements. Please use angle steel flanges or reinforce according to the design and specification requirements.

5、风管分支管制作：在风管系统中（不论是定风量或变风量），弯头、三通位置不得直接开分支管，该部位会产生涡流，形成很大的阻力，使各个分支管风量难以调节，而且会产生局部噪音。

5. Production of air duct branch pipes: In air duct systems (whether it is a constant or variable air volume), the elbow and tee positions should not directly open the branch pipes. This area will generate eddy currents, creating great resistance, making it difficult to adjust the air volume of each branch pipe, and will generate local noise.

上述这5个方面是风管制作时需要注意的，每一个方面总结的还是比较细致的，所以大家在之后的制作中要注意相应的处理，一定要规范进行，保证之后的使用效果。更多相关事项就来我们网站http://www.sftfgd.com咨询！

The above five aspects need to be noted during the production of air ducts, and each aspect is summarized in detail. Therefore, everyone should pay attention to the corresponding treatment in the future production, and must carry out it in a standardized manner to ensure the effectiveness of future use. For more related matters, come to our website http://www.sftfgd.com consulting service
