双面彩钢玻纤风管管道使用

发布人：http://www.sftfgd.com   发布时间：2023-03-07 15:03:48

玻纤复合风管是为了适用新技术、新材料而研制的一种新型风管，以超细纤板为基础，经特殊加工复合而成。集保温、消声、防潮防火、防腐、美观（适合明装）外层强度高，内层表面防霉等多项功能于一体，具有重量轻，漏风量小、制作安装快、占用空间小，通风好、性能比较合理等优点。尤其是它优良保温和消声性能被广大用户所偏爱。与传统工艺风管相比，它还能为用户节省管道系统投资20%左右。

Glass fiber composite air duct is a new type of air duct developed for the application of new technologies and new materials. It is based on ultra-fine fiber board and is specially processed and compounded. It integrates many functions such as heat preservation, noise elimination, moisture-proof and fire-proof, anti-corrosion, beauty (suitable for open installation), high strength of outer layer, mildew-proof and antibacterial of inner layer surface, and has the advantages of light weight, small air leakage, fast production and installation, small space occupation, good ventilation, and reasonable performance and price. In particular, its excellent thermal insulation and noise elimination performance is preferred by the majority of users. Compared with traditional process air duct, it can also save about 20% of pipeline system investment for users.

玻纤复合风管复合玻璃棉板经刀具切割、粘合、密封胶带密封和加固而成。复合玻璃棉板的双护层为玻璃纤维布复合铝箔或内护层为玻璃棉板。玻璃棉板采用离心法形成的玻璃纤维加树脂胶经热压、固化成型。板的常规格：密度 70~75kg\m2, 厚度 25mm 。

The glass fiber composite air duct composite glass wool board is made by cutting, bonding, sealing and strengthening with sealing tape. The double protective layer of composite glass wool board is glass fiber cloth composite aluminum foil or the inner protective layer is glass wool board. The glass wool board is formed by centrifugal method with glass fiber and resin adhesive, and then hot pressed and solidified. Normal specification of plate: density 70~75kg  m2, thickness 25mm.

由于复合玻璃棉板夹层为多孔轻质材料、寻热系数低，吸声系数大，因而玻纤复合风管具有良好的保温和消声性能；同时，风管具有材质轻、施工周期矩、防火、防潮、无有害挥发物、外形美观、使用寿命长、造价低等特点。复合玻纤风管与镀锌钢板风管加保温比较，可节省工程费用 30% 以上，尚不包括节省的消场设备费用，是低、中压空调通风系统更为经济、适用的一种通风管道。

Because the sandwich of the composite glass wool board is made of porous lightweight material, with low heat seeking coefficient and large sound absorption coefficient, the glass fiber composite air duct has good heat preservation and noise elimination performance; At the same time, the air duct has the characteristics of light material, short construction period, fire prevention, moisture prevention, no harmful volatiles, beautiful appearance, long service life and low cost. Compared with galvanized steel duct with insulation, composite glass fiber duct can save more than 30% of the project cost, excluding the cost of field elimination equipment. It is the most economical and applicable ventilation duct for low and medium pressure air conditioning and ventilation systems.

产品参数:

Product parameters:

1、防火等级（GB8624—1997）：阻燃A级

1. Fire rating (GB8624-1997): Flame retardant grade A

2、容重65-80kg/立方米

2. Unit weight 65-80kg/m3

3、吸水率小于0.5%

3. Water absorption is less than 0.5%

4、导热系数：在室温24，产品导热系数小于0.035V/M?K

4. Thermal conductivity: at room temperature of 24, the thermal conductivity of the product is less than 0.035V/M? K

5、耐热性能-50~120

5. Heat resistance - 50~120

6、压缩强度10%：0.29Mpa

6. Compression strength 10%: 0.29Mpa

7、甲醛释放量0.00，mg/L(标准 1.5)

7. Formaldehyde emission 0.00, mg/L (standard 1.5)
