通风设备管道制作方法及要求

发布人：http://www.sftfgd.com   发布时间：2023-11-04 10:37:46

通风、空气调节工厂所使用的主要材料、设备、成品办成品等均应有出厂合格证明书或质量鉴定文件。通风工厂必须按批准的设计图纸施工。通风管道制作的尺寸应按图施工，均以内径为准，连接管应与阀体相吻合。圆形弯管的弯曲半径和少节数及矩形弯管的弯曲半径应按《建筑安装工程施工技术操作规程》中有关规定执行。圆形风管的三通，其夹角为90o。风管各管段的连接应采用可拆卸的形式。风管厚度按标准。

The main materials, equipment, finished products, etc. used in ventilation and air conditioning factories should have factory certificates of conformity or quality appraisal documents. The ventilation factory must be constructed according to the approved design drawings. The size of the ventilation pipeline production should be constructed according to the drawing, and the inner diameter should be used as the standard. The connecting pipe should match the valve body. The bending radius and number of small sections of circular bends, as well as the bending radius of rectangular bends, should be executed in accordance with the relevant provisions of the "Technical Operation Regulations for Construction and Installation Engineering". The tee of a circular air duct has an included angle of 90o. The connection of each section of the air duct should be in a detachable form. The thickness of the air duct shall comply with the standard.

部件安装前应进行如下检查，经检查合格并填写有关验收资料后方可进行安装：风口表面应平整，偏差<=2mm，矩形风口对角线之差<=3mm，圆形风口任意正交两直径的允许偏差<=2mm。风口各转动部分应灵活，叶片或插板应平直，叶片内距应均匀，散流器的扩数环和调节应同轴，轴向间距分布匀称，叶片等启闭应完全，人防密闭阀方向与冲击波相准确，不可装反，叶片全开或全闭，不可作调节风量之用。各类阀门制作应牢固，调节制动装置应准确灵活、可靠，并标明阀门启闭方向，防火阀壳体厚度应大于等于2mm，材料选用应符合GB50243-97规范要求。柔性短管人防滤毒系统选用橡胶型，其他选用三防防火帆布，各吊、支、托架，应平整牢固，焊缝饱满，抱箍的圆弧应均匀。

Before installing the components, the following inspections should be carried out. After passing the inspection and filling in relevant acceptance materials, the installation can only be carried out: the surface of the air outlet should be flat, with a deviation of<=2mm, the difference between the diagonal lines of the rectangular air outlet<=3mm, and the allowable deviation between any two orthogonal diameters of the circular air outlet<=2mm. The rotating parts of the air outlet should be flexible, the blades or insert plates should be straight, the internal distance between the blades should be uniform, the expansion ring and adjustment of the diffuser should be coaxial, the axial spacing should be evenly distributed, the opening and closing of the blades should be complete, the direction of the civil air defense sealing valve should be accurate with the shock wave, and cannot be reversed. The blades should be fully open or fully closed, and cannot be used for adjusting the air volume. The production of various types of valves should be firm, the adjustment and braking device should be accurate, flexible, and reliable, and the valve opening and closing direction should be indicated. The thickness of the fire valve shell should be no less than 2mm, and the material selection should comply with the requirements of GB50243-97 specification. The flexible short pipe civil air defense and gas filtration system adopts rubber type, while the other uses three proof fireproof canvas. Each suspension, support, and bracket should be flat and firm, with full welds, and the arc of the hoop should be even.

管道在安装前应对其除尘，保证管道内外表面整洁，管道在安装前应检查其平整和水平度，经监理或甲方认可并填写有关验收资料后方可安装。管道吊装前先要核对现场结构预留孔洞的位置、尺寸、标高，并将风管内外擦拭干净，严防施工中的垃圾管道中，安装部位的障碍物要清理。

Before installation, the pipeline should be dedusted to ensure the cleanliness of the internal and external surfaces. Before installation, the pipeline should be checked for flatness and levelness, and can only be installed after being approved by the supervisor or Party A and filling in relevant acceptance materials. Before lifting the pipeline, it is necessary to check the position, size, and elevation of the reserved holes in the on-site structure, and wipe the inside and outside of the air duct clean to strictly prevent garbage from being left in the pipeline during construction. Obstacles in the installation site should be cleaned.

管道和配件可拆卸的接口，不得装设在墙和走道楼板内。支、吊、托架的预埋件或膨胀螺栓，位置应准确、牢固可靠，埋入部分不得油漆，并应支除油污。不保温支、吊、托架间距无设计要求应遵照下列执行。水平安装：风管直径或大边长小于40mm，间距<=4m;大于或等于400mm，则间距≤3m。垂直安装：间距<=4m但每根立管的固定件应大于等于2个。保温管应符合设计要求。支、吊、托架不得设置在风口、阀门、检视门外。吊架不得直接吊在法兰上，并在适当处设防止摆动的固定点。防火阀、电动风阀等部件安装处必须单独设吊支架。法兰的垫料厚度为3—5mm，塑料不得凸入管内。连接法兰的螺栓。其螺母应在同一侧，材质按设计要求进行。风管水平安装，水平度应<=3/1000，总偏差应<=20mm。风管垂直安装，垂直度应<=2/1000，总偏差应<=20mm。人防出墙风管按人防要求作坡度。风管的阀类调节部门应安装在便于操作的部位，阀板应顺气流方向插入，防火阀安装位置应正确，易熔件应在系统安装后装入。各类风口安装应平整，位置准确。转运部分应灵活，与风管连接应牢固。柔性短管安装松紧适当，不得扭曲。

The detachable interfaces of pipes and accessories shall not be installed in walls and walkway floors. The embedded parts or expansion bolts of supports, hangers, and brackets should be positioned accurately, firmly, and reliably. The embedded parts should not be painted, and oil stains should be removed. The spacing between non insulated supports, hangers, and brackets should comply with the following design requirements. Horizontal installation: The diameter or major side length of the air duct is less than 40mm, and the spacing is<=4m; If it is greater than or equal to 400mm, the spacing≤ 3m. Vertical installation: spacing<=4m, but the fixed parts of each riser should be no less than 2. The insulation pipe should meet the design requirements. Supports, hangers, and brackets shall not be installed outside air vents, valves, or inspection doors. The hanger shall not be directly hung on the flange, and fixed points shall be set at appropriate locations to prevent swinging. Separate suspension brackets must be installed at the installation locations of fire dampers, electric dampers, and other components. The gasket thickness of the flange is 3– 5mm, plastic should not protrude into the pipe. Bolt connecting the flange. The nuts should be on the same side, and the material should be made according to the design requirements. The air duct should be installed horizontally, with a levelness of<=3/1000 and a total deviation of<=20mm. The air duct should be installed vertically, with a verticality of<=2/1000 and a total deviation of<=20mm. The air duct for civil air defense shall be sloped according to the requirements of civil air defense. The valve adjustment department of the air duct should be installed in a convenient location for operation, the valve plate should be inserted in the direction of the airflow, the installation position of the fire damper should be correct, and the fusible parts should be installed after the system is installed. The installation of various air vents should be flat and accurately positioned. The transfer part should be flexible and firmly connected to the air duct. The flexible short pipe should be installed with appropriate tightness and should not be twisted.
